13
1. Introduction
Table 1.6 Configuration Options Configuration letters Configuration options Setting configurations
LA101 Configurations:
B Sequence bank User, Lindos, Tape, Speaker, Filter, Meter, Utility, BBC,
BT, Telecom Australia, SAPO
F Frequency display Rounded, true
R Remote baud rate 75, 150, 300, 1200, 2400, 4800, 9600, 110
S Start up level MUTE, p/set 1, p/set 2, p/set 3, p/set 4, p/set 5, previous
value
T Start up frequency p/set 1, p/set 2, p/set 3, p/set 4, p/set 5, previous value
U Level units dBu/dBm, dBV, Volts and dBu/dBm, Volts and dBV
V Monitor volume Off, Remote error beep, 2,3,4,5,6,7,8,9,10,11,12,13,14,15
W Weighting on
All, usr1, usr2, usr3, usr4, usr5, RIAA, CCIR, CCITT, 50
µs
Z Output impedance 10
, 75 , 600
Default options (shown in bold) are: B0 F1 R3 S4 T4 U0 V8 W0 Z1
LA102 Configurations:
A Auto Print Seq Off, On, 2 Copies, 3 Copies, 4 Copies, 0 copies Multiple copies
B Printer baud rate 75, 150, 300, 1200, 2400, 4800, 9600, 110, 19200
C Compartments per memory 1, 2, 3, 4, 5
D Distortion display %, dB
E Graph width Normal (6cm), Wide (12cm), difference
F Graph fit 0dB, Peak, Centre 0dB
G Graph scale in dB/cm 1/4, 1/2, 1, 2, 4, 8
H Graph height in cm 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10
I Lines per inch 6, 7, 8, 9
J Graph normalisation Absolute, 315Hz, 400Hz, 1kHz
M Top margin in 1/6" lines 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12
N Page length in 1/6" lines 60-76 lines, default is 66 (ie 11")
P Printer type ASCII text only, Epson FX LX RX/IBM (9pin), P40 (40
col), P40 (80 col), HP Thinkjet, Epson NLQ, Apple
Imagewriter, Epson LQ (24 pin), HP Deskjet 100dpi, HP
Deskjet 150dpi, CSV
R Remote baud rate 75, 150, 300, 1200, 2400, 4800, 9600, 110
S Softstrip output No longer available (contact Lindos)
T Tolerance None, User 1, 2, 3, 4, 5, Selftest, EPS81A <40km, EPS84
<40km, EPS84 <320km,EPS98 <320km, IBA Tape/
general, IBA Tape/restricted, IBA Studio path, Lindos
cassette, Studer A812 stereo 15ips
Tolerance configuration
U Level units dBu/dBm, dBV, V, W
V Monitor volume 0 (off), 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16
W Watts into 8
display V, V/10
X Date operation Not printed, printed, advanced at switch on
Y Auto store SEQ results Off, in memory 1-5 next
Z Input impedance 600
, 10k
Default options (shown in bold) are:
A0 B7 C1 D2 E1 F1 G5 H4 I6 J3 M0 N66 P1 R3 T1 U0 V8 W1 X0 Y0 and Z2
