Lindos LA100 - Pre-Defined Tolerances in the LA102

90
0 None
1-10 User Tolerances
11 IBA Tape/General
TV +-1
PQRSUX +6,+2-2.5<3,,,,+-1<1.5,,,,,,,,,+2-2.5<3,,,?
CJ -17,-25,-36,,,-32
B -25,-36,,-32
I -34,,-40
MN -41,-45,-41
YZ +-60,+-35,+-15,+-30,+-46,+-60
W .12,,+-15,+-.3
12 IBA Tape/Restricted Use
TV +-1.5
PQRSUX +6,+3.5-2.5<3,,,,,+-1.5<2,,,,,,,,+3.5-
2.5<3,,,?
CJ -17,-25,-36,,,-32
B -25,-36,,-32
I -28,,-30
MN -36,-40,-36
YZ +-180,+-90,,,,+-180
W .15,,+-90,+-.5
13 IBA Studio Path Standard
T +-0.5
PQRSUX +6,+-1<1,,,,+-0.5<0.5,,,,,,,,,+-1,,,+6
MN -60,-63,-60
I -46,,-52,
CJ -35,-43,-53,,,-49
B -43,-53,,-49
YZ +-20,+-16,+-10,+-14,+-17,+-20
14 Lindos Cassette
PQRSUX ?,+-3,,,+-2,,,,,,,,+-3,,,,,?
MN -40
CJ -20,,-30
B -20,-30
I -30,-28,-36,-40
W 0.12,,+-20,+-1
YZ +-60,+-35,+-15,+-30,+-45,?
5. Tolerance Testing
Table 5.3 Pre-Defined Tolerances in the LA102 V6.5 Software
15 Studer A812 15ips
PQRSUX +-2,+-1,,,,,,,,,,,,,,,,,,+-2
MN -50,-59,?
L -63,?
D ?,-40,?
F ?,,,-40,?
C ?,,,-65,?
B ?,-65,?
W 0.04,,?,+-0.2
16 Lindos LA100 Self Test
!3
U +0-.15,,+-.1,,+-.05,,,,,,,,,,+-.10
T +-.05
L -107,-105
MN -95,-98,-95
C -90,,,-80
D -80,-86,-76
Z +-2
17 British Telecom EPS81 <40km
TV +-1
O ?,+.75-1,,,+-.75,,,,,,,,,,,,,,+.75-3,,?
E -35,?,-40
MN -45,-35,-45
18 British Telecom EPS84 <40km
TV +-1
O +.5-1<1,,,,+-.5<.5,,,,,,,,,,,,,,,,+.5-1<1,,,,+.5-
2<3,?
BCJ -56
E -50,?,-50
MN -59,-44,-59
YZ +-18,+-15,+-9,+-15,+-16,+-18
19 British Telecom EPS84 <320km
TV +-1
O +.5-2<1,,,,+-.5<.5,,,,,,,,,,,,,,,,+.5-2<1,,,,+.5-
2<3,?
BCJ -56
E -50,?,-50
MN -52,-44,-52
YZ +-18,+-15,+-9,+-15,+-16,+-18
20 British Telecom EPS98 <320km
TV +-1.5
O ?,+.75-3.25,,,+.75-2.75,,,,,,,,,,,,,,+.75-
6.25,,?
E -35,?,-40
MN -44,-35,-44
Tolerance definitions Selftest tolerance Pre-defined tolerances Studer A812 Cassette
tolerance EPS81 EPS84 EPS98 British Telecom specification Built-in tolerances
