20
LEVEL
1 RMS, 2-100kHz
2 RMS, 22-22kHz
3 VU 22-22kHz
4 Twin level and phase bar graphs
5 PPM 22-22kHz
6 VU, A weighted
7 RMS, A weighted
8 VU 2-100kHz
9 RMS 2-100kHz slow response
10 PPM 2-100kHz
11 RMS 400-100kHz
12 RMS 400-22kHz
13 VU 400-22kHz
14 Twin bar 400-100kHz
15 PPM 400-22kHz
NOISE
1 CCIR468-3 weighted quasi-peak
2 CCIR468-3 unweighted quasi-peak
3 RMS 22-22kHz
4 RUMBLE unweighted, slow
5 RUMBLE weighted, slow
6 CCIR weighted, ARM-1k
7 CCIR weighted, RMS
8 A weighted, RMS
9 CCIR weighted, ARM-2k
10 2-100kHz
, quasi-peak
11 Unused
12 CCIR unweighted, 400-22kHz
13 RMS, 400-22kHz
14 CCIR unweighted PPM
15 CCIR weighted PPM
to selects options 1-5
to selects 6-10
to selects 11-15
returns to options 1-5
CROSSTALK
1 100Hz narrow band, RMS
2 315Hz narrow band, RMS
3 1kHz narrow band, RMS
4 6.3kHz narrow band, RMS
5 10kHz narrow band, RMS
6 40Hz narrow band, RMS
7 150-300Hz narrow band, RMS
8 2k-20kHz narrow band, RMS
9 15kHz narrow band, RMS
DISTORTION
1 100Hz RMS THD, 200-22kHz
2 315Hz RMS 3rd harmonic, narrow band
3 1kHz RMS THD, 2k-22kHz
4 6.3kHz RMS THD, 12k-22kHz
5 10kHz RMS THD, 20k-22kHz
6 40Hz RMS 2-400Hz
7 1kHz RMS 3rd harmonic - experimental
8 1kHz notch only, 22-22kHz
9 6.3kHz notch only, 22-22kHz
10 10kHz notch only, 22-22kHz
11 100Hz CCIR weighted quasi-peak
12 Unused
13 1kHz CCIR weighted quasi-peak
14 6.3kHz CCIR weighted quasi-peak
15 10kHz CCIR weighted quasi-peak
WOW & FLUTTER etc
1 W&F IEC386 weighted quasi-peak
2 W&F IEC386 unweighted quasi-peak
3 Q-D 40Hz CCIR weighted quasi-peak
4 Q-D 40Hz RMS, 400Hz-22kHz
5 Difference frequency distortion, 70Hz RMS
6 W&F weighted RMS
7 W&F unweighted RMS
8 FIM (frequency intermod)
11 Speed (3150Hz reference)
12 Speed (3125Hz reference)
13 Speed (3kHz reference)
Table 2.6 Measurement Options Measurement option
2. Manual Operation
