Controls & Connections: REAR PANEL
4•5
And finally, the MAIN row gives you easy access to the most-used AX2 controls.
Everything's covered in detail in the oft-promised Working It chapter.
Option Lists
This information is here so that you’ll know almost everything you need to edit your
sound without having to keep looking at this User Guide. Not only that, but it gives
you something to read when you’re playing at one of those clubs where you have to
wait for the manager to turn off the jukebox before you can start your set.
Signal Flow
Another handy reference. Just so you know what goes before and after what.
REAR PANEL
AC power connector
We didn’t bother to put it on the road map; we figure you can probably find it. The end
of the power cord that won’t fit into the wall socket goes here.
Power switch
Also not on the road map. We figured you’d find it OK on your own. Little red push
button. On or Off? You decide.
Speaker Jacks
Plug the speaker cables into these (actually, we already did that when we put your
AX2 together). If you’re going to drive an external speaker cabinet with your AX2,
make sure that the cabinet has an impedance of 8 ohms or greater. Also, note that you
can just unplug the speakers here if you want to record or practice silently using the
direct recording/headphone output. Unlike some tube-based power amplifiers, it is
perfectly OK to run the AX2’s amplifiers with no speaker load.
MIDI In/Out
Use these to connect a MIDI floor controller or to connect to a computer with a MIDI
15
16
17
18
