 Use the buttons and to add the flashing digit and move to

editing to the next. Edit this value of divisions so that the multimeter

indicates 4mA in the case of setting or 0 mA if .

 Press to confirm. The display shows the message , as the

instrument waits for the value of the DAC divisions corresponding to

20mA.

 Press to start editing, edit the value using the buttons and

until the multimeter does not indicate 20mA (default: ).

Press to confirm.

 The last parameter to edit is if the analogue output must follow the trend of

the net or gross weight. The display shows the message corresponding to

the current set (default ). Use the button to select

or . Press to confirm.

 At this point the instrument will show the written and the

procedure is finished.
