Page 23 / 43
6.
Set the current desktop height on the display.
Press memory position key 1 to increase the desktop
position displayed.
Press memory position key 2 to decrease the desktop
position displayed.
7.
Press the memory key. The display will show the
current desktop position (display no longer flashing).
Danger: intelligent system protection (ISP) is not enabled during all
resets and limit position calibration. Please note that there is a potential
risk of pinching in this case.
4.3 Software-dependent functions
Note: prior to shipping, the COMPACT control unit is parameterized with
the software. The following functions are only available if the control unit
has been configured accordingly.
4.3.1 Slow speed ranges
This function (low speed) automatically slows down the desktop during adjustment
before it reaches the following positions:
• Highest and lowest desktop positions
• All saved positions
4.3.2 Safety area
This function triggers a safety stop at a defined desktop position (configured with the
software). The safety stop functions as follows:
1.
Press the desktop down key (and hold it down). The desktop will
move to the start of the safety area.
2.
The desktop movement will stop just before the safety area.
3.
Press the desktop down key again. The desktop will then move to
the lowest position.
Note: you cannot save desktop positions in safety areas.
Note: this function is available for both motorgroups separately. Please
read the manual of the used handswitch to see which buttons are linked
to which motor group!
