Page 30 / 43
5. Technical data
General
Supply voltage EU: 207-254,4V / 50Hz
US: 90-127V / 50-60Hz
Standby power, primary (typical) <0.6W
Efficiency factor (typical) 83% @ 300W input power
Op
erating voltage for internal and external
electronics and Hall sensors
5VDC ±10% 250mA
Precision of Motor current measurement
@ 100% Output Voltage and 4-8A per Motor
±20%
Contact LOGICDATA
Ambient temperature 0-30°C
Relative humidity (for operation) 5-85% (non condensing)
Storage and transport temperature -40-85°C
Relative humidity (for storage) 5-90% (non condensing)
Protection class (with earth terminal) I
Power cord (length) 3m ± 50mm
Dimensions (L x B x H) [mm]
Tolerances
264 x 103 x 37
according to DIN ISO 2768-1 c
COMPACT-3
Output Power and sum currents for all motor
channels
Hi Power cycle:
20s UP: 17,5A@20V 350W
20s DOWN: 6,5A@33V 214,5W
Pause: 9min
Normal cycle 1/9:
30s UP: 14A@24V 336W
30s DOWN: 6,5A@33V 214,5W
Pause: 9min
Normal cycle 2/18:
2min move: 6,5A@33V 214,5W
Pause: 18min
Max. current per motor channel 8A per motor channel
Maximum sum current restricted,
values shown above
Weight (typical) 598g
