SMARTNEO OPERATING MANUAL // PAGE 15
5.2 REQUIRED COMPONENTS
1 SMARTneo-2G or SMARTneo-3G Control Box
2 Mounting Screws (supplied by reseller)
4-5 Cable Clamps (supplied by Reseller)
Tool Drill or Drilling Machine
Tool Screwdriver
INFO The mounting points for the SMARTneo-2G / SMARTneo-3G have a diameter of 5,5
mm. The Mounting Screws should hold the SMARTneo-2G / SMARTneo-3G safely and
securely in place. Exact specications can be provided by LOGICDATA on request.
INFO Strained or loose Cables may lead to insecure connections. Insecure connections
may cause ISP malfunctions (such as false triggers) and lead to system damage.
LOGICDATA recommends the use of Cable Clamps to ensure Cables are kept in place
during movement of the Table Top. Cable Clamps are provided by the Reseller. Exact
specications can be provided by LOGICDATA on request.
5.3 PROCESS
WARNING Moderate risk of serious injury through electric shocks
While using the SMARTneo-2G / SMARTneo-3G, liquid intrusion may lead to serious
injury through electric shocks.
• Ensure components are placed away from areas where spillages may occur
• Take care not to spill liquids onto or around the Control Box.
NOTICE LOGICDATA does not restrict customers to specic mounting positons for the
SMARTneo-2G / SMARTneo-3G. However, mounting the Control Box incorrectly
may cause the collision detection system to malfunction. To ensure correct installa-
tion, all Table Tops must be tested thoroughly (dierent materials, thicknesses, etc.).
Additionally:
• Ensure there is no gap between the SMARTneo-2G / SMARTneo-3G and the Table
Top at the mounting points. The Control Box must be tightly secured with no mo-
vement possible.
• Ensure the mounting surface is smooth, at, and undamaged.
• Ensure the entire housing of the SMARTneo-2G / SMARTneo-3G is placed underne-
ath the Table Top.
• Ensure the Control Box is installed and used within the ambient conditions speci-
ed in the product datasheet.
• Use Cable Clamps to secure connections and reduce the risk of ISP malfunction.
• If the collision detection system is not working properly, contact LOGICDATA.
