SMARTNEO OPERATING MANUAL // PAGE 34
10.2 CLICK CODES
As soon as the Control Box is connected, the control box uses installed relays to inform the user about sys-
tem status and the reason for the last shutdown:
CLICKS MESSAGE
2x Normal operation: The system is working normally.
1x
Emergency operation: The system is in emergency operation mode. The actuator
cannot be used. Check the error code.
3-6x
Last shut-o incomplete / forced reset: Check the error code. If the control
box could not complete a data-saving process before power was lost, it will click
4–5 times during its next start-up and go into reset mode. Error code 81 will not be
shown in this case.
10.3 ERROR MESSAGES ON THE DISPLAY
When a Comfort Hand Control is installed, error messages are displayed on the digital display panel.
SIGNAL MESSAGE REQUIRED ACTIONS
Hot
The display shows
“Hot” or „System
Pause“.
Overheating protection has been
activated. Duty cycle possibly
exceed.
Wait for the overheated components to cool.
E00
The display shows
an error number.
An internal error has occurred. Read the table below to nd the correct
response to the error code shown.
CODE MESSAGE REQUIRED ACTIONS
E00
Internal Error Channel 1 Disconnect the Control Box from the Mains.
Contact LOGICDATA for further information.
E02
Internal Error Channel 2
Hot
