SMARTNEO OPERATING MANUAL // PAGE 19
6.5 CONNECTION VIA THE DC/COM PORT (OPTIONAL)
The DC/COM interface of the SMARTneo-2G / SMARTneo-3G may only be used to connect compatible, cer-
tied, LOGICDATA approved external devices. The external device must have a current-limiting component
in its output circuit (e.g. a fuse) to limit the maximum current to 10 A. Contact LOGICDATA for instructions
and safety advice.
6.6 CONNECTING TO THE MAINS
WARNING Moderate risk of death or serious injury through electric shocks
Connecting the SMARTneo-2G / SMARTneo-3G to the mains incorrectly may lead to
death or serious injury through electric shocks.
• Ensure the mains voltage is compliant with the voltage specied on the SMARTneo-
2G / SMARTneo-3G‘s Type Plate
• Do not attempt to force or bend connectors
1. Plug the Power Cable into the AC Plug Port of the SMARTneo-2G / SMARTneo-3G
2. Connect the Power Cable to the mains.
6.7 PERFORMING A POSITION RESET PROCEDURE
CAUTION Risk of minor or moderate injury through crushing
Collision Detection (ISP) is inactive during start-up and reset processes. This may lead
to minor or moderate injury through crushing.
• Ensure that no persons or objects are in the table‘s range of motion
NOTICE Operating the table system when it is not properly connected can damage the product.
• Ensure all Cables are properly connected
• Ensure that all required Actuators are ready to be operated
• Do not operate the Table System until it is properly connected
The Position Reset Procedure is used to align the position of the Actuators within the Table System. You
must perform a Position Reset Procedure before using the SMARTneo-2G / SMARTneo-3G for the rst time.
It is possible to perform a Position Reset Procedure with all types of compatible User Interface. However,
this section describes performing a Position Reset Procedure for Table Systems controlled by a Hand Control
with an UP Key and DOWN Key (Comfort or Basic Hand Controls).
If your SMARTneo-2G / SMARTneo-3G is operated by a dierent User Interface, consult that product’s ope-
rating Manual for instructions on performing a Position Reset Procedure.
