SMARTNEO OPERATING MANUAL // PAGE 17
6 CONNECTING THE SYSTEM
WARNING Moderate risk of death or serious injury through electric shocks
Connecting the system incorrectly can lead to death or serious injury through electric
shocks.
• Ensure that the supplied voltage complies with the SMARTneo-2G / SMARTneo-
3G‘s type plate
• Ensure all components are connected to the correct sockets
• Do not use unauthorized accessory parts or cables
• Disconnect the SMARTneo-2G / SMARTneo-3G from the power outlet before remo-
ving or connecting any components
• Connect the system to the Mains only after all other components (Actuators, User
Interfaces, etc.) have been connected to the SMARTneo-2G / SMARTneo-3G
WARNING Moderate risk of death or serious injury through electric shocks
Using damaged products may lead to death or serious injury through electric shocks.
• Do not use the SMARTneo-2G / SMARTneo-3G if you see the housing or cables are
damaged
NOTICE Ensure proper ESD handling during assembly. Damage that can be attributed to elec-
trostatic discharge will void warranty claims.
INFO Perform a product risk assessment so that you can respond to potential residual ha-
zards. Assembly instructions must be included in your end user Operating Manual.
6.1 SYSTEM CONFIGURATION
The SMARTneo-2G / SMARTneo-3G can be used to create a variety of Table Systems. This Manual describes
the connection of table systems in which only one Control Box will be connected. For Table Systems with
more than one Control Box, refer to the SMARTneo-2G Cascading Manual (applies also to SMARTneo-3G)
for assembly and safety advice. This Manual describes Table Systems that will be powered using mains elec-
tricity. For usage with other types of power source, refer to the Manual of the chosen product.
6.1.1 REQUIRED COMPONENTS: SYSTEM WITH 1 ACTUATOR
1 SMARTneo-2G or SMARTneo-3G Control Box
1 Actuator
1 User Interface (see Chapter 6.3)
1 Mains Cable (2-pin connection, C7)
To Next Page
