SMARTNEO OPERATING MANUAL // PAGE 31
1. Perform a Factory Reset (Chapter 8.3)
2. Disconnect the Control Box from the mains and wait for 10-15 seconds
3. Disconnect the existing SLIMdrives from the Plug Ports M1/M2 (optional)
4. Connect the new type of SLIMdrive to the Plug Ports M1/M2 (optional)
5. Reconnect the Control Box to the mains
▸ The error code E70 will appear on the Hand Control
6. Perform a Position Reset Procedure (Chapter 6.7)
▸ You can now use the table system as normal
9.3 AUTO-DETECT: CHANGING THE NUMBER
OF SLIMDRIVES
NOTICE In Cascading Systems, this process will only aect the Actuators attached to the master
Control Box. Refer to the Cascading Manual to avoid system damage.
NOTICE Auto-Detect settings depend on the parameterization of the Control Box. Contact
LOGICDATA before attempting to change the table conguration.
The Control Box can automatically detect how many SLIMdrives are connected to the system. This means
that you can change the number of SLIMdrives the Control Box must control without changing the parame-
terization of the control box. To change the number of SLIMdrives to be controlled:
1. Perform a Factory Reset (Chapter 8.3)
2. Disconnect the Control Box from the mains and wait for 10-15 seconds
3. Connect/Disconnect SLIMdrives at Plug Ports M1/M2 until you have the desired number.
4. Reconnect the Control Box to the mains
▸ The error code E70 will appear on the Hand Control
5. Perform a Position Reset Procedure (Chapter 6.7)
▸ You can now use the table system as normal
9.4 CHANGING THE NUMBER OF ACTUATORS (OTHER)
CAUTION Risk of injury through incorrect installation
Only Skilled Persons have the expertise to complete this process safely. Installation by
unskilled persons can lead to minor or moderate personal injury or system damage.
• Ensure that only Skilled Persons are allowed to complete the installation.
• Refer to Chapter 2.8 to ensure that personnel meet all requirements.
NOTICE The menu has a timeout of 5 seconds. If no entry is made in this time, it will close wit-
hout saving settings.
