SMARTNEO OPERATING MANUAL // PAGE 30
9 ACTUATOR SETUP
9.1 PLUG DETECTION
The SMARTneo-2G and SMARTneo-3G feature Plug Detection. This means that the Control Box recogni-
zes when an Actuator is connected to the M1 or M2 Plug Port and when an Actuator has been removed or
replaced. If an Actuator has been removed from Plug Port 1 or 2, the Control Box will click three times. If
a Comfort Hand Control is installed, the error code E36, E37, or E38 will be shown, depending on which
Actuator was removed.
When an Actuator has been removed or replaced, the process you need to follow diers depending on how
the Control Box will continue to be used. Options are as follows:
• If you wish to change the type of LOGICDATA SLIMdrive connected to the Control Box (e.g. for
SLIMdrive-660s to SLIMdrive-500), but you do not want to change the number of connected
SLIMdrives, go to Chapter 9.2, SLIMdrive Detection: Changing to a Dierent SLIMdrive Type.
• If you wish to change the number of LOGICDATA SLIMdrives connected to the Control Box, go
to Chapter 9.3, Auto Detect: Changing the Number of SLIMdrives.
• If you wish to change the number of Actuators (any type) to the Control Box, go to Chapter 9.4,
Changing the Number of Actuators (other).
• If you wish to continue with the same type and number of Actuators, proceed as follows:
1. Disconnect the Control Box from the mains and wait for 10-15 seconds
2. Reconnect the missing Actuators to Plug Ports M1/M2 (optional)
3. Reconnect the Control Box to the mains
4. Perform a Position Reset Procedure (Chapter 6.7)
▸ You can now use the table system as normal
9.2 SLIMDRIVE DETECTION: CHANGING TO A
DIFFERENT SLIMDRIVE TYPE
NOTICE Ensure that the Actuator(s) have been safely assembled into the Height-Adjustable
Columns before connecting. Refer to the Actuator‘s Manual to avoid system damage.
With certain parameterization, the SMARTneo-2G and SMARTneo-3G can automatically detect which type
of SLIMdrive is connected at the Plug Ports M1/M2 (i.e. SLIMdrive-660s or SLIMdrive-500). Proceed as fol-
lows to change the type of LOGICDATA SLIMdrives connected to the Control Box:
