SMARTNEO OPERATING MANUAL // PAGE 37
11 ADDITIONAL INFORMATION
Technical data for the Control Box and all other products in the Table System can be found in each product‘s
corresponding datasheet.
11.1 DISASSEMBLY
To disassemble the Table System, rst disconnect the Control Box from the mains. Then, follow the assem-
bly instructions in reverse order.
11.2 COLLISION DETECTION
11.2.1 INTELLIGENT SYSTEM PROTECTION
Intelligent System Protection (ISP) is LOGICDATA’s collision detection system. It aims to reduce the risk
of system damage when using LOGICDATA products. When a collision is detected, all Actuators stop im-
mediately and move back in the opposite direction for a few seconds (see 11.2.2 Drive Back Function). The
SMARTneo-2G features integrated collision detection function via the Light Barrier sensor, and SMARTneo-
3G via gyroscope. No external sensors are required. The following points must be observed regarding the
ISP function.
• ISP sensitivity and ISP shutdown values depend on the complete system (mechanical and elect-
ronic components). Contact LOGICDATA to determine the ISP suitability of your Table System.
• After ISP is activated, the next movement of the system can only be in the opposite direction.
• ISP shutdown values can be adjusted in the parameters of the Control Box. Contact LOGICDATA
for further details.
11.2.2 DRIVE BACK FUNCTION
After ISP is triggered, the Table Top automatically moves a dened distance in the opposite direction.
