Thank you for choosing a machine from
LOGOSOL.
Logosol has manufactured small-scale sawmills since
1988. Our most renowned product is the LOGOSOL
SAWMILL, the world’s best selling sawmill in all
categories.
Logosol has a wide range of equipment for small-scale
wood processing, covering machines and aids that
enables you to control the entire process single-handed,
from felling to nished product.
Logosol also manufactures cutting equipment for industrial
production: the RIP SAW ASSISTANT, a cutting aid that
is mounted above the circular saw blade, the CIRCULAR
RESAW, and the STACK CUTTER.
Contact Logosol, and we will send you information about
the entire range of products. If you are interested in a
specic product, we have lms that show the machines in
action. On our website you can see short versions of the
lms, but if you want the longer, more detailed versions,
we send you those (on videotape or DVD) by post. This
is, of course, free of cost.
You have bought PH 260, a 4-sided planer/moulder
that has many good qualities. If you have any questions
about your PH 260, do not hesitate about contacting us
at Logosol. Our aim is to make you yet another satised
owner of one of our products.
We wish you the best with your new machine!
Bengt-Olov Byström
MD and founder of Logosol
Table of Contents
Safety Instructions 4
Safety Distance 5
Tools Needed 6
List of Components 7
Overall View 8
Machine Description 10
Setting up the PH 260 10
Planer Shavings Collection 10
In- and Out-Feed Tables 11
Control Panel 12
Lower Horizontal Cutter 13
Upper Horizontal Cutter 14
Moulding Knives in Upper and Lower Cutters 15
Side Cutters 16
Belt Transmissions 20
Feeder 21
Feed Rollers 21
Levelling the Machine Table 22
Accessories 23
Maintenance 25
Knives; Planing/Moulding with LOGOSOL PH 260 26
Planing/Moulding Tips 28
Starter package PH260: moulding knives &
examples of combinations 30
Troubleshooting 33
Circuit Diagram, 400 V 3-phase 38
Circuit Diagram, 230 V 3-phase 39
Circuit Diagram, 230 V 1-fas 40
Technical Data 41
Declaration of Conformity 41
Knives and Accessories
There is a wide range of accessories for PH 260, such as
chip extractors, hoses, in-and out-feed tables, and other
useful items. Besides the broad selection of standard
knives, Logosol has developed a line of knives that are
especially suitable for planing with the PH 260.
All this is presented in Logosol’s Moulding Knives
Catalogue (ref. no. 7005-000-0520) which can be ordered
free of charge from Logosol.
A selction of accessories is also presented under the
section Accessories on page 23.
Printed on chlorine-free, recyclable paper, using inks
based on vegetable oil.
LOGOSOL is constantly developing its products. For that
reason we reserve the right to make changes in the design
and construction of our products.
Text: Mattias Byström and Anna Olsgren Byström
Translation: Anna Olsgren Byström
Document: PH 260 Manual
Illustrations: Mattias Byström, Bo Mårtensson and Bo
Hellborg
Latest revision: 2014-09-08
Manual, ref. no: 0458-395-0170
Copyright 2001 LOGOSOL, Härnösand Sweden
