4
*Numbers within parentheses refer to the list of components
and the overall view on pp.7-9.
If used incorrectly, the PH 2660 can cause serious injury.
Always be focused and careful when using the machine.
Never stand behind the work piece when it is being fed into
the machine. The board can be hurled out of the machine. Also
knots, splinters or pieces of steel can be hurled out with great
force. Always stand at the side of the in-feed table.
Only one work piece at a time may be fed through the
machine. The work piece must be of a length of at least 600
mm (24 inches).
Make sure that the machine is set up so that the feed rollers
(3*) take a rm hold of the work piece. Do not feed into the
machine work pieces that are so conical that the feed rollers
risk losing hold.
Never place your hands or tools above or beneath the machine
table while the machine is running.
Before starting the machine:
- Make sure that no other person besides the operator is within
the safety distance (see p.5).
- Make sure that all cutters can rotate freely, and that no tools
or loose parts are left inside the machine.
- Make sure that all knobs, screws, nuts, fences, knife
clamping gibs, cutter heads, knives, protective covers, in-
and out-feed tables, etc. are rmly tightened/attached.
Safety Instructions
For your own safety, do not begin working
with the machine before having read and
understood the entire manual. Do not let
anyone who has not read the instructions use
the equipment.
Risk of cutting injuries. Use protective gloves
when handling the knives. It is especially
important that you wear gloves when loosening
or tightening the lock screws for the knives and
the fences (as there is a risk that you slip with
the spanner).
Use approved hearing protectors. Hearing
can be impaired after only a short exposure
to high-frequency sounds. Use approved eye
protectors. Splinters and wood pieces can be
hurled out with great force.
Warning! Cutting tools. Never stick hands or
tools above or beneath the machine table
or in the chip outlets while the machine is
running.
This symbol means “WARNING”. Pay extra
attention when this symbol appears in the
text.
This symbol is followed by an admonition. Pay
extra attention when this symbol appears in
the text.
- Make sure that the machine runs in the correct direction:
seen from the left side of the machine the in-feed roller
should rotate clockwise. If the machine is not running in the
correct direction, change the direction by rotating the white
plastic disc in the connection plug with a at screwdriver.
- Make sure that the cover is properly closed, that all chip
hoses are mounted, and that you have switched on the chip
extractor.
In this manual, the phrase ”disconnect the power” means
that you shall stop the machine, pull out the power cable with
the CEE plug, which supplies the machine with electricity, and
place it so that no unqualied operator can connect it to the
machine. The cable shall also be placed so that you cannot
tread or trip on it.
Disconnect the power to the machine by pulling out the
plug, and wait for the cutter heads to stop before:
- opening the cover to change planing/moulding knives, or to
clean or carry out any other operation above or beneath the
machine table.
- replacing belts or performing any other servicing or
cleaning.
- moving the machine.
- leaving the machine unsupervised.
Risk of re and dust emission when collecting wood debris.
Chip hoses and a chip extractor must be connected to the chip
outlets of the machine, and be fastened in a reliable way, e.g.
with hose clamps. Take necessary measures to prevent re in
the chip collecting equipment.
The machine must be equipped with in- and out-feed tables of
a length of at least 1 metre (3.28 ft) each.
Do not wear loose-tting clothing or anything else that can get
caught in the machine’s moving parts. If you have long hair you
should put it up in a reliable way.
Never use the machine in poor visibility conditions. Always work
in good lighting.
Do not use the machine under the inuence of alcohol or other
drugs.
Keep the work site tidy. Do not leave anything you can trip over
lying on the ground.
Never put your hands or any tools on the machine table while
the machine is running.
Never stick your hands or any tools in the chip outlets until you
have made sure that the power to the machine is disconnected
and the cutters have stopped.
Do not climb onto the machine.
Do not tread on the machine’s power cable. The cable should
be secured off the ground.
Place the machine so that the emergency stop is not blocked.
For the greatest electrical safety, a residual circuit breaker
should be tted.
