Technical data
Dimensions and weight
Length 1170 mm (46”)
Height 1200 mm (47”)
Width 850 mm (33.5”)
Weight 350 kg (772 lb)
Timber dimensions
Moulder
Max. width 260 mm (10”)
Height 10 to 80 mm (0.4” to 3”)
Planer
Max. width x height 410 x 230 mm (16” x 9”)
Cutter 1, horizontal lower cutter
Diameter 72 mm (3”)
Width 300 mm (12”)
Continuous output 3 kW
Speed of rotation 6000 rpm
Chip thickness 4 mm
Max. knife pattern protrusion 4+15 mm
Cutter 2 and 3, vertical cutters
Spindle diameter 30 mm (1”)
Max. cutter height* 80 mm (3”)
Max. cutter diameter 140 mm (5.5”)
Continuous output 3 kW
Speed of rotation 6000 rpm
Chip thickness approx.: 30 mm
Cutter 4, horizontal upper cutter
Diameter 72 mm (3”)
Width 410 mm (16”)
Continuous output 3,0 kW
Speed of rotation 6000 rpm
Chip thickness approx.: 10 mm
Max. knife pattern protrusion 10+10 mm
*With certain limitations 100mm (4”).
Feeder
5 rollers run by a 0.18 kW motor via a chain transmission
with the speed of approx. 6 m/min. (20 ft/min.).
As an accessory Logosol offers a planetary gear
that makes it possible to adjust the feeding speed
steplessly.
Standard equipment
2 knives for each horizontal cutter.
2 vertical cutters with 50 mm planing knives.
Tools for adjusting the knives and cutters.
Declaration of conformity
Machine Directive 89/392/EEG
Amendment 2, section A
AFS 1994:48, Amendment 2, section A
The manufacturer, MOReTENs AB, M10, Lungviksvägen
147, S-831 52 ÖSTERSUND, hereby declares that the
planer/moulder Logosol PH260 is manufactured in accor-
dance with AFS 1994:48 Machines and Other Technical
Contrivances, or corresponding national directives in other
countries within EES that corresponds to the Machinery
Directive: (89/392/EEG with the amendments 91/44/EEG,
91/368/EEG and 93/68/EEG).
The manufacturer also declares that Logosol PH260 is
manufactured in accordance with (parts of) the following
harmonized standards: EN 292-2
Östersund 1997
Bo Mårtensson, MD
Electrical system
CCA 16A 400V 50Hz 3-phase (alt. 230V 3-phase 25A)
Coupled enclosure, degree of protection IP54.
Thermal cut-out on each motor.
0-tension release.
Protective cover equipped with safety switch.
Sound levels
Empty machine, 73.2 dB(A), in operation 99.6 dB(A).
Addition for measuring accuracy K=4 dB(A). Values
measured in workshop environment.
