Basic System Setup4
Step 1 of 2 — Option B: Connecting cameras to your local network using power adapters:
1. Connect each camera to a compatible power adapter (check your camera documentation at
lorex.com for compatible power adapters for your cameras).
2. Connect the camera to your router using a CAT5e or higher Ethernet cable.
Step 2 of 2: Add the cameras to your NVR:
1. Right-click and select Device Search.
2. Click Device Search. The system searches the network for compatible cameras.
NOTE
It may take a few minutes after you power up IP cameras for them to appear in your search.
3. Check the camera(s) you would like to add.
4. Click Add. The Status indicator turns green to show the camera is successfully connected.
NOTE
You can also add a camera to a specific channel by hovering the mouse over an empty channel in split-screen
view and clicking
. Double-click the camera you would like to add, then right-click to exit.
#LX400113; r. 9.0/57191/57191; en-US 11
