Using the Main Menu17
2. Click EVENTS, then click the Event Settings tab on the side panel. In the drop down click
the Safeguard tab.
3. Under Camera, select the channel you would like to configure.
4. Click on Add to create a new rule.
5. Under Types select Missing for object’s that are missing from the designated area or Left
Behind for object’s that have been left behind in the designated area.
6. Once the type of rule has been chosen, click the
Draw icon to edit the rule size and cov-
er area.
• Select any anchor point of the polygon shape to adjust the rule size and area to filter for
Missing or Left Behind objects.
• Name the rule area.
• Enter the Period in seconds before an event is triggered.
• Once done click OK.
7. Click the
Trigger icon to choose which actions to perform when the safeguard rule is
triggered.
8. Click Apply to save changes.
#LX400113; r. 9.0/57191/57191; en-US 78
