Using the Main Menu16
2. Click , then click STORAGE. Click the HDD MANAGER tab on the side panel.
3. Click the Type drop-down under the second hard drive and select Mirror.
CAUTION
Setting a hard drive for mirroring erases all data on the hard drive. This step cannot be undone.
4. Click Apply to apply changes. Click Yes to confirm. The system will format the hard drive
and restart.
5. When the system restarts, right-click to open the Quick Menu, then click Main Menu. Click
, then click STORAGE. Click the SCHEDULE tab on the side panel, then Re-
cord on the top panel.
6. Under Channel, select the channel you would like to enable for mirror recording.
#LX400113; r. 3.0/56326/56332; en-US 93
