Replacing the Hard Drive19
The system comes with a pre-installed 3.5" SATA hard drive. You can replace the hard drive with
one up to a maximum size of 10TB, and add a second drive if you choose to.
19.1 Removing the Hard Drive
CAUTION
Make sure that the system is OFF and the power adapter is disconnected before removing/installing a hard drive.
To remove the hard drive:
1. Power off the system, and unplug all cabling from the system.
2. Remove the back panel screws (4×). Remove the cover by sliding it backwards.
3. Turn the recorder over carefully. Remove the 2 hard drive screws closest to the edge of the re-
corder. Loosen the remaining 2 hard drive screws, but do not remove them.
#LX400113; r. 3.0/56326/56332; en-US 113
