Using the Main Menu16
2. Click
, then click EVENT. Click the WARNING tab on the side panel, then click
the Fan tab on the top panel.
3. Check Enable to activate fan warnings.
4. Configure the following for the selected event type:
• Alarm Out: Check the box to activate alarm output devices (not included) when the se-
lected event occurs. Select the alarm output devices that will be activated, then enter the
number of seconds the alarm output device(s) will activate after the selected event occurs
next to Latch.
• Show Message: Check to show a popup message when the selected event occurs.
• Send Email: Check to enable email alerts. You must configure email alerts before you will
be able to receive them (see 16.4.4 Configuring Email Alerts, page 78).
• Buzzer: Check to activate the system buzzer.
5. Click Apply to save changes.
16.4.12 Configuring Alarm Input Devices
You can connect alarm input devices such as motion sensors (not included) or glass break detec-
tors (not included) to the system. The system can be set to trigger recording or take other actions
when these devices are activated.
To connect alarm devices:
• Connect the included green alarm blocks to the back panel of the recorder.
• Connect your alarm device according to the supplied documentation.
To configure alarm input devices (not included):
1. From the Live View display, right-click to open the Quick Menu, then click Main Menu.
#LX400113; r. 3.0/56326/56332; en-US 86
