MAINTENANCE MANUAL OF ENGINE
48
3.2 Dismantling the piston connecting rod assembly
Attention:
Clear the carbon deposition on upper cylinder head.
If it is not cleared or not cleared fully, it may cause
damage to the piston ring.
1. Push out the piston connecting rod assembly
from one side of crankshaft by stick or rubber rod.
A-Piston connecting rod assembly
Attention
Assemble the connecting rod bearing shell and
connecting rod cap after piston connecting rod is
dismantled and place in sequence.
To Next Page
