MAINTENANCE MANUAL OF ENGINE
67
3.3 Dismantle fan components
1. Dismantle fan set bolt A
A-Set bolt
2. Dismantle fan A
A-Fan
3. Dismantle fan belt
A-Fan belt
A
A
A
