MAINTENANCE MANUAL OF ENGINE
87
4. Dismantle the bolt, and remove the fuel pipe A
from the fuel filter to the fuel injection pump.
A-Hollow bolt
B-Fuel pipe from the fuel filter to the fuel injection
pump
5. Dismantle the remaining fuel pipeline A.
A-Other pipeline
B
A
A
