Technical catalog for Susol & Metasol ACB
Technical catalog for Susol & Metasol ACB
A
AN-10D3-10J
Metasol Series
D1
Closing power suppy
D0
D1
D2
D3
D4
D5
D6
D7
C.C Not Provided
AC / DC100~130V
AC / DC200~250V
DC 125V
DC 24~30V
DC 48~60V
AC 380V~480V
AC 48V
D1
Trip power suppy
D0
D1
D2
D3
D4
D5
D6
D7
SHT Not Provided
AC / DC100~130V
AC / DC200~250V
DC 125V
DC 24~30V
DC 48~60V
AC 380V~480V
AC 48V
AX
Aux.contact & Charging types
AX
AC
BX
BC
HX
HC
CC
JC
Low capacity OFF charge 3a3b
Low capacity ON charge 3a3b
Low capacity OFF charge 5a5b
Low capacity ON charge 5a5b
High capacity OFF charge 5a5b
High capacity ON charge 5a5b
Low capacity ON charge 6a6b
High capacity ON charge 6a6b
NGO
OCR
B / C
OPTION
M1
Motor power suppy
MA
M1
M2
M3
M4
M5
M6
M7
M8
Motor Not Provided
AC / DC100V~130V
AC / DC200V~250V
DC 125V
DC 24V~30V
DC 48V~60V
AC 380V~480V
AC 440V~480V
AC 48V
U1
UVT
U0
U1
U2
U3
U4
U5
U6
U7
UVT Not Provided
AC / DC 100V~130V
AC / DC 200V~250V
DC 125V
DC 24V~30V
DC 48V~60V
AC 380V~480V
AC 48V
UVT Delay usable from AC / DC 48V
Metasol
Rated current(CT SFEC)
OCR & CT Not Provided
200A
400A
630A
800A
1000A
1250A
1600A
00
02
04
06
08
10
13
16
No. of pole
3 : 3 poles(D)
4 : 4 poles(D,W)
D : 630~2,000AF
3/4P
Standard type
RST(N)
W : 630~2,000AF
4P
Reverse phase type
NRST
Frame sizes &
Phase array
AN 103D10
10
13
16
-
08
08
2,000AF
2,500AF
3,200AF
3 : 3 poles(E)
4 : 4 poles(E,X)
-
20
25
32
-
00
06
08
10
13
16
20
25
32
OCR & CT Not Provided
630
800
1,000
1,250
1,600
2,000
2,500A
3,200A
-
630AF
800AF
1,000AF
1,250AF
1,600AF
Installation
J
A
H
V
M
N
P
L
J
Draw-out type
Fixed type
Manual Connection
Autometic Connection
AMPERE
FRAME
E : 630~4,000AF
3/4P
Standard type
RST(N)
X : 630~4,000AF
4P
Reverse phase type
NRST
Horizontal Connection
Vertical Connection
Top horizontal /
Bottom vertical type
Top vertical /
Bottom horizontal type
Front connection
Separate order /
Installation on user’s side
To Next Page
