118

Technical catalog for Susol & Metasol ACB

2) Arrange two shutter plates facing each other in the assembly process.

3) Place Shutter plate at an angle as shown in figure below after pushing GUIDE ASSY completely. Insert the

bottom of Shutter plate first and then put the projections of BASE into the assembly hole of Shutter.

4) Move Shutter plate toward right side.

Before Assembly After Assembly

Projections for Assembling Shutter of BASE

Shutter Plate Assembly Groove
