1. Externals
It interlocks with the mechanism of circuit breaker
and indicates the status that the circuit breaker is
ready to do closing operation.
When mechanism is in OFF position or in CHARGE.
Contact is output with ONand it indicates that
mechanism can be closed.
2. Installation Method
1) Put ready-to-close contact into the inserting/assembly hole of mechanism.
Ready-to-Close Contact
2) Tighten with M4 bolt by using wrench.
AContact
Assembly
Hole
Inserting
Hole
Contact Part
