Technical catalog for Susol & Metasol ACB

1. Main Body Mounting

To prevent the manual operation of closing / Trip button by mistake

1. Installation Method

1) Install it to the correct place of Front cover.

ON / OFF Button Lock

2) Install ON / OFF BUTTON LOCK by using two bolt screws to pass through the holes on inside Front cover as

shown in figure above.

ON /OFF BUTTON LOCK
