116

Technical catalog for Susol & Metasol ACB

1. Externals

It is the automatic safety device which prevents the connectors of main circuit from being contacted with outside

when drawing out ACB and Shutter is only opened during draw-in operation.

There are 4 types of Safety Shutter and they are divided as shown in figure below.

The Types of Safety Shutter Plate

2000, 5000AF/3P 2000, 5000AF/4P 4000, 6300AF/3P 4000, 6300AF/4P

Installation Numbers : 4ea(2000, 4000AF ) / 8ea (5000,6300AF )

Safety Shutter

Plate

Guide Assy
