2. Installation Method

1) It is mounted into cradle and easily attachable. Insert 2 GUIDE ASSY into the hole on BASE ASSY of cradle

first as shown in figure below.

Note 1. It can be installed only when putting it into the knob with its own particular direction.

Note 2. Two of GUIDE ASSY has the exactly opposite direction for insertion.

CRADLE

No.1. GUIDE ASSY No.2. GUIDE ASSY

GUIDE ASSY
