20
Technical catalog for Susol & Metasol ACB
Technical catalog for Susol & Metasol ACB
B
There are many possible terminal configurations when connecting bus bar of distribution panel, vertical, horizontal,
plane type, etc.
ON button
OFF button
Series name
Rated name plate
Charge Discharge indicator
ON/OFF indicator
Arc box
Charge handle
Drawout handle
Handle storage space
Pad lock button
Position indicator
Arc Cover
Digital trip relay
Terminal cover
■
Fixed Type
■
Draw-out Type
Fig.1 Horizontal type Fig. 2 Vertical type Fig.3 Horizontal/Vertical type
Fig.4 Vertical/Front type Fig.5 Front/Vertical type Fig.6 Front type
Fixed Type / Draw-Out Type
Terminal Configuration
