96
Technical catalog for Susol & Metasol ACB
Technical catalog for Susol & Metasol ACB
I
2. Installation Method
1) The figures below show the Safety shutter connected with Sutter lock. The arrow printed on Guide shutter
and Shutter lock should be upwards.
Mounting direction of Shutter lock Guide shutter
2) Lock after setting up Key lock through Shutter lock as shown in figure to make Guide shutter not pushed.
Apply same installation method to opposite side.
Guide Shutter
Shutter Lock
Key
Key Lock
