LS Industrial Systems SV-iE5 Series User Manual

Chapter 3. Wiring
3-4
3.5 PNP/NPN Modes Switch
Internal Power
[NPN](up)
Using
internal
24V
External power
[PNP](down)
Using
external
24V
Voltage input[ V ] (right)
Analogue
voltage input
Current input[ I ] (left)
Analogue
current input
Note
The setting direction of switch in the
above figure is in black.
P1 P2 P3 P4 P5 CM
P1 P2 P3 P4 P5 CM
 24
Vd
2) Using external voltage
1) Using external current
0~20mA
AI CM
0~10Vdc
AI CM
1~10kΩ
VR AI CM
3) Using variable resistor
