LS Industrial Systems SV-iE5 Series User Manual

Chapter 1. Basic Information and Precaution
1-2
1.2 Parts’ Names and Details
 Appearance
 Inside view with front cover removed
Refer to 1.3 for details when remove front cover.
Front cover:
Removed when wiring
and installing
Status LED display
Inverter nameplate:
Indicating the capacity
and rating of the
inverter
Variable resistance for
frequency setting
RUN button
Cover screws
Power input
NPN, PNP Select
switch
COM part: built in for
COM type product
Inverter ground
terminal
Versatile relay output
terminal
Control signal terminal
Motor output (lower)
DC power (upper)
Analogue input select
switch
