LS Industrial Systems SV-iE5 Series User Manual

Chapter 9. Specifications
9-1
9. Specifications
9.1 Technical data
 Input and output ratings
Type : SV xxx iE5 – x 001-1 002-1 004-1 001-2 002-2 004-2
1)
Motor
[HP] 1/8 1/4 1/2 1/8 1/4 1/2
[kW] 0.1 0.2 0.4 0.1 0.2 0.4
Output
ratings
2)
Capacity[kVA] 0.3 0.6 0.95 0.3 0.6 1.14
Current [A] 0.8 1.4 2.5 0.8 1.6 3.0
Output frequency 0 ~ 200 [Hz]
Voltage [V]
3)
3phase 200 ~ 230V
Input
ratings
Voltage [V]
1phase 200 ~ 230 VAC
(±10%)
3phase 200~230 VAC
(±10%)
Frequency
50 ~ 60 [Hz] (±5%)
Current[A] 2.0 3.5 5.5 1.2 2.0 3.5
 Control
Control method v/f
Frequency setting
resolution
Digital command : 0.01Hz
Analog command : 0.1Hz (max. fre : 60Hz)
Frequency accuracy
Digital command: 0.01% of Max output frequency
Analog command: 0.1% of Max output frequency
v/f pattern Linear v/f, Squared v/f
Overload capacity 150% per min.
Torque boost Manual/Auto torque boost
1)
Motor shows the max. capacity assuming that 4 poles standard motor is used.
2)
Ratings are based on 220V.
3)
Max. output voltage may not be over the power voltage. Output voltage may be
set temporarily lower than the power voltage.
