LS Industrial Systems SV-iE5 Series User Manual

Chapter 9. Specifications
9-2
 Operation
Operation mode Select one of loader/terminal/COM operation(optional)
Frequency setting
Analogue: 0 ~ 10[V], 0 ~ 20[mA], loader volume
Digital: loader
Operation features PI, up-down, 3-wire
Input
Multi-function
terminal
P1, P2, P3, P4,
P5
NPN / PNP selectable (see page 3-5)
Functions: FWD/REV RUN, Emergency stop, Fault
reset, Jog operation, Multi-step Frequency-
High & Low,
Frequency UP/Down, 3-wire operation, External trip A &
B, PI-
Inverter (v/f) operation bypass, Analog Hold,
Accel/Decel stop, Up/Down Save Freq.
Multi-function
relay
Fault output and
inverter status
output
Less than (N.O., N.C.) AC250V
0.3A
Less than DC 30V 1A
Analog output
0 ~ 10 Vdc (less than 10mA) : frequency, current,
voltage, DC voltage selectable
 Protective function
Trip
Over Voltage, low
voltage, over current, ground fault detection,
inverter overload, overload trip, inverter overheat, condenser
overload, output phase loss, overload protection, frequency
command loss, hardware fault.
Alarm
Stall prevention
Momentary
power loss
Below 15 msec: Continuous operation (should be within rated input
voltage, rated output power.)
Above 15 msec: Auto restart enable
 Structure and Environment
Cooling Natural cooling
Protection type Open(IP 20)
Ambient temperature
-10°C ~ 40°C
Storage temperature
-20
°
C ~ 65
°
C
Ambient humidity Less than 90% RH (non-condesing)
Altitude, vibration Below 1,000m, below 5.9m/sec
2
(0.6G)
Environmental
conditions
Protected from corrosive gas, combustible gas, oil mist or
dust
