LS Industrial Systems SV-iE5 Series User Manual

Chapter 1. Basic Information and Precaution
1-1
1. Basic Information and Precaution
1.1 Important precautions
Unpacking
and
Inspection
Unpack the package and check the inverter type, output ratings on
the nameplate and whether
the inverter is intact. In addition,
inspect the inverter for any damage that may have occurred during
shipping.
SV 004 iE5 - 1 C
Motor rating Series name Input power
RS-485
option
001
0.1 [kW]
Extra small
commercial
inverter
1
Single
C
No
002 0.2 [kW]
2
3 Phases
200V
-
C
No
option
004 0.4 [kW]
 Accessories
If you have found any discrepancy, damage, etc., c
ontact your
dealer or sales representative (refer to the rear cover page of this
manual).
Preparations
of
instruments
and parts
required for
operation
Instruments and parts to be prepared depend on how the inverter
is operated. Prepare optional (additional) equipments and parts as
necessary.
Installation
To operate the inverter with high performance for a long time,
install the inverter considering a proper place and
the correct
direction with proper clearances.
Wiring
Connect the power supply, motor and
operation signals (control
signals) to the terminal block. Note that incorrect connection may
damage the inverter and peripheral devices.
Inverter type
Rated output spec.
Inverter capacity
Barcode and serial number
Manufacturer and
Manufacturing country
Rated Input spec.

LS Industrial Systems SV-iE5 Series Specifications

General

Brand	LS Industrial Systems
Model	SV-iE5 Series
Category	Inverter
Language	English
