LS Industrial Systems SV-iE5 Series User Manual

Chapter 7. Function List
7-3
Display Name
Min/Max
range
Description
Factory
defaults
Adj.
during
run
P 0
Jump code
0 ~ 88
Sets the code number to jump
1
O
P 1 Fault log 1 -
It logs the information on the types of
faults, and the frequency, current and
status such as acceleration,
deceleration and stop at the time of
trouble. The latest fault is automatically
recorded in log 1.
nOn -
P 2
Fault log 2
-
-
nOn
-
P 3
Fault log 3
-
-
nOn
-
P 4
Fault log
removal
0 ~ 1 Remove log P1~P3. 0 O
P 5
Prohibition
of
forward/rev
erse
rotation
0 ~ 2
0 Both F/R directions available
0 X
1 Forward rotation prohibited
2 Reverse rotation prohibited
P 6
Acc pattern
0 ~ 1
0
Linear pattern operation
0 X
P 7
Dec pattern
1
S-curve pattern operation
P 8
Stop mode
selection
0 ~ 2
0
Deceleration to stop
0 X 1 DC brake to stop
2
Free run to stop
P 9
1)
DC brake
start
frequency
0.1 ~ 60
[Hz]
It sets DC brake start frequency.
It cannot be set below start
frequency(P18).
5.00 X
P10
DC brake
wait time
0 ~ 60
[sec]
When DC brake frequency is reached,
the inverter holds the output for the
setting time before starting DC brake.
0.10 X
P11
DC brake
voltage
amount
0 ~ 200
[%]
It sets the amount of DC voltage
applied to a motor. Motor rated
current(P43).
50 X
P12
DC brake
time
0 ~ 60
[sec]
It sets the time taken to apply DC
current to a motor.
1.0 X
1)
Displayed only when P8 is set to 1(DC brake to stop).
