LS Industrial Systems SV-iE5 Series User Manual

Chapter 7. Function List
7-4
Display Name
Min/Max
range
Description
Factory
defaults
Adj.
during
run
P13
DC brake
start
voltage
0 ~ 200
[%]
It sets the amount of DC voltage before
a motor starts to run. Motor rated
current(P43)
50 X
P14
DC brake
start time
0 ~ 60
[sec]
It applies the current to a motor for the
set time before motor accelerates.
0.0 X
P15
Jog
frequency
0 ~ 200
[Hz]
It sets the frequency for jog operation. It
cannot be set above the max
frequency(P16).
10.00 O
P16
Max
frequency
40 ~
200
[Hz]
This parameter sets the upper limit
frequency.
It is frequency reference for
Accel./Decel.
60.00 X
Note
If changing the max frequency, all other
frequency parameters but P17(base
frequency) would be changed to the
frequency if they are above the new
max. frequency.
P17
Base
frequency
30 ~
200
[Hz]
The inverter outputs its rated voltage to
the motor at this frequency.
60.00 X
P18
Start
frequency
0.1 ~ 10
[Hz]
The inverter starts to output its voltage
at this frequency.
It is lower frequency limit of
frequency(Hz).
0.5 X
P19
Torque
boost
selection
0 ~ 1
0 Manual torque boost
0 X
1 Auto torque boost
P20
Forward
torque
boost
0 ~ 15
[%]
Torque boost amount of motor during
forward run, based on max. output
voltage.
5.0 X
P21
Reverse
torque
boost
Torque boost amount of motor during
reverse run based on max. output
voltage.
5.0 X
P22
V/F
pattern
0 ~ 1
0 Linear
0 X
1 Square
