LS Industrial Systems SV-iE5 Series User Manual

Chapter 7. Function List
7-5
Display Name
Min/Max
range
Description
Factory
defaults
Adj.
during
run
P23
Output
voltage
adjustment
40 ~
110
[%]
It adjusts the amount of output voltage,
based on the percentage of input
voltage.
100 X
P24
Overload
trip
selection
0 ~ 1
This parameter turns off the inverter
output when motor is overloaded.
Overload protection function works if it
is set to 1.
1 0
P25
1)
Overload
trip level
50 ~
200
[%]
It sets the amount of overload current,
based on the percentage of Motor
rated current(P43)
180 0
P26
Overload
trip time
0 ~ 60
[sec]
It turns off the inverter output when
overload trip level current(P25) flows
for overload trip time.
60 0
P27
Stall
prevention
select
0 ~ 7
Sets stall prevention function
0 X
Func.
Set
During
dec.
During
constant
run
During
acc.
bit 2
bit 1
bit 0
0
-
-
-
1
-
-

2
-

-
3
-
 
4

-
-
5

-

6
 
-
7
  
P28
Stall
prevention
level
30 ~
150
[%]
It sets the amount of current to activate
stall prevention function, based on the
percentage of the motor rated
current(P43).
150 X
P29
Save
up/down
frequency
0 ~ 1
It decides whether to save the specified
frequency during up/down operation.
If 1 is selected, the up/down frequency
is saved in P30.
0 X
P30
2)
Save
Up/Down
-
It saves the frequency before the
inverter stops or decelerated.
0.00 -
1),2)
Set P24 and P29 to 1 to display this parameter.
