Learning Basic Features
118
Code
Description
acceleration will be applied within the 30-45 Hz frequency range. The
inverter will perform an S-curve acceleration for the remaining
acceleration in the 45–60 Hz frequency range.
ADV-05 Dec S
Start –
ADV-06 Dec S End
Sets the rate of S-curve deceleration. Configuration for codes ADV-05
and ADV-06 may be performed the same way as configuring codes ADV-
03 and ADV-04.
[Acceleration / deceleration pattern configuration]
[Acceleration / deceleration S-curve parrten configuration]
