Learning Advanced Features
Set <6: Aux5> of [AP1-98 AuxRunTime Clr]
2
Aux Motor3 (00:30)
<Operating>
Aux Motor2 (00:40)
<Operating>
Aux Motor1 (00:50)
<Operating>
Aux Motor 5 (0)
<Stopping>
Aux Motor 4
(01:30)
<Stopping>
Set time of Aux5 to 2:00 through [AP1-97 AuxRunTime Min]
3
Aux Motor3 (00:30)
<Operating>
Aux Motor2 (00:40)
<Operating>
Aux Motor1 (00:50)
<Operating>
Aux Motor4 (01:30)
<Stopping>
Aux Motor 5
(02:00)
<Stopping>
5.44.6 Regular Bypass
This function controls the motor speed based on the feedback amount instead of using the
PID. Auxiliary motors may be controlled with this feature based on the feedback amount.
Group
Code
Name
LCD Display
Parameter Setting
Setting
Range
Unit
AP1
41
Bypass selection
Regul Bypass
1
0
No
-
-
1
Yes
61–
65
#1–5 auxiliary motor
start frequency
Start Freq 1–
5
Frequency value
within the range
Freq Low
Limit–Freq
High limit
Hz
70–
74
#1–5 auxiliary motor
stop frequency
Stop Freq 1–
5
Frequency value
within the range
Low Freq–
High Freq
Hz
OUT
31–
35
Multi-function
relay1–5
Relay 1–5
21
Multiple motor
control (MMC)
-
-
36
Multi-function 1 item
Q1 Define
40
KEB
Operation
-
-
Regular Bypass Detail Settings
