Learning Advanced Features
Sets the regular bypass mode.
Sets the auxiliary motor start frequency.
Sets the auxiliary motor stop frequency.
OUT-31–35 Relay 1–5
OUT-36 Q1 Define
Set OUT31–35 to ‘21 (MMC)‘ to use the out terminal for auxiliary
motor operation. The number of configured output terminals
determines the total number of auxiliary motors to be used.
When an input set by the PID feedback of the analog input terminal (I or V1 or Pulse) is
100%, divide the area by the number of motors being used (including the main motor).
Each auxiliary motor turns on when feedback reaches the relevant level and turns off when
feedback goes below the relevant level. The primary motor increases its speed based on
the feedback and when it reaches the start frequency of the relevant auxiliary motor and
decelerates to the stop frequency. The primary motor reaccelerates when the frequency
increases, depending on the feedback increase. If the relevant auxiliary motor is turned off
because of the feedback decrease, the primary motor accelerates from the stop frequency
to the start frequency.
To use the regular bypass function, ‗1 (Yes)‘ has to be selected in the MMC and PID
functions. Only FILO operates between the AP1-49 (FIFO/FILO) in a regular bypass
function.
