LSIS H100-2 - Total Memory Map for Communication

357
RS-485 Communication Features
Group
Code
Name
LCD Display
Parameter
Setting
Setting range
Unit
CNF
48
Save parameters
Parameter
Save
0
No
0–1
-
1
Yes
7.3.3 Total Memory Map for Communication
Communication Area
Memory Map
Details
Communication common
compatible area
0h0000–0h00FF
iS5, iP5A, iV5, iG5A, S100, H100
compatible area
Parameter registration type area
0h0100–0h01FF
Areas registered at COM-31–38 and
COM-51–58
0h0200–0h023F
Area registered for User Group
0h0240–0h027F
Area registered for Macro Group
0h0280–0h02FF
Reserved
communication common area
0h0300–0h037F
Inverter monitoring area
0h0380–0h03DF
Inverter control area
0h03E0–0h03FF
Inverter memory control area
0h0400–0h0FFF
Reserved
0h1100
DRV Group
0h1200
BAS Group
0h1300
ADVGroup
0h1400
CON Group
0h1500
IN Group
0h1600
OUT Group
0h1700
COM Group
0h1800
PID Group
0h1900
EPI Group
0h1A00
AP1 Group
0h1B00
AP2 Group
0h1C00
AP3 Group
0h1D00
PRT Group
