8.9 EPID Function Group (EPID)
51
Data in the following table will be displayed only when the related code has been selected.
Unit MAX = EPID1 (EPID2) Unit 100%
Unit Min = (2xEPID1 (EPID2) Unit0%-EPID1 (EPID2) Unit100%)
Unit Default = (EPID1 (EPID2) Unit 100%-EPID1 (EPID2) Unit 0%)/2
*O/X : Write-enabled during operation,Δ: Writing available when operation stops
Code
Comm.
Address
Name
LCD
Display
Setting Range
Initial
Value
Property*
Ref.
00
-
Jump
Code
Jump
Code
1–99
1
O
p.65
01
0h1901
EPID 1
Mode
Selection
EPID1
Mode
0
None
0: None
O
p.179
1
Always
ON
2
During
Run
3
DI
depende
nt
02
52
0h1902
EPID1out
put
monitor
value
EPID1
Output
-100.00–
100.00%
0.00
X
p.179
03
0h1903
EPID1
standard
monitor
value
EPID1 Ref
Val
-
-
X
p.179
04
0h1904
EPID1
feedback
monitor
value
EPID1
Fdb Val
-
-
X
p.179
05
0h1905
EPID1erro
r monitor
value
EPID1 Err
Val
-
-
X
p.179
51
EPID Group is displayed when PID-02 code is set to 'Yes'.
52
EPID-02–20 are displayed when EPID-01 code is not ‗0 (None)‘.
