Learning Advanced Features

224

Title

Setting Range

Remarks

Except1–8 StartT

00: 00–24: 00

Hour: Minutes (by the minute)

Except1–8 Stop T

00: 00–24: 00

Hour: Minutes

Except1–8 Date

1/1–12/31

Select the particular date (between 1/1 and 12/31)
