Learning Advanced Features
Operation State Monitor Setting Details
Code
Description
CNF-20 AnyTime
Para
Select items to display on the top-right side of the keypad screen.
Choose the parameter settings based on the information to be
displayed. Codes CNF-20–23 share the same setting options as listed
below.
Setting
Function
0
Frequency
On stop, displays the set frequency. During
operation, displays the actual output
frequency (Hz).
1
Speed
On stop, displays the set speed (rpm). During
operation, displays the actual operating speed
(rpm).
2
Output
Current
Displays output current.
3
Output
Voltage
Displays output voltage.
4
Output Power
Displays output power.
5
WHour
Counter
Displays inverter power consumption.
6
DCLink
Voltage
Displays DC link voltage within the inverter.
7
DI Status
Displays input terminal status of the terminal
block. Starting from the right, displays P1–P8.
8
DO Status
Displays output terminal status of the terminal
block. Starting from the right: Relay1, Relay2,
and Q1.
9
V1 Monitor[V]
Displays the input voltage value at terminal V1
(V).
10
V1 Monitor[%]
Displays input voltage terminal V1 value as a
percentage. If -10 V, 0 V, +10 V is measured,
-100%, 0%, 100% will be displayed.
13
V2 Monitor[V]
Displays input voltage terminal V2 value (V).
14
V2 Monitor[%]
Displays input voltage terminal V2 value as a
percentage.
15
I2 Monitor[mA]
Displays input current terminal I2 value (A).
16
I2 Monitor[%]
Displays input current terminal I2 value as a
percentage.
