Installing the Inverter
20
3 Remove the keypad from the inverter body.
0.75–30 kW Models
37–90 kW Models
4 Loosen the screws securing the front cover, and remove the front cover by lifting it. The
main PCB is exposed.
0.75–30 kW Models
37–90 kW Models
