RS-485 Communication Features
Comm.
Address
Address
Parameter
Scale
Unit
R/W
Assigned Content by Bit
28: Communication
option
30: JOG, 31: PID
B8
0: Keypad
1: Fx/Rx-1
2: Fx/Rx-2
3: Built-in 485
4: Communication
option
5: Time Event
B7
B6
R/W
B5
Reserved
B4
Emergency stop
B3
W: Trip initialization
(01),
R: Trip status
B2
Reverse operation (R)
B1
Forward operation (F)
B0
Stop (S)
0h0007
Acceleration time
0.1
sec
R/W
-
0h0008
Deceleration time
0.1
sec
R/W
-
0h0009
Output current
0.1
A
R
-
0h000A
Output frequency
0.01
Hz
R
-
0h000B
Output voltage
1
V
R
-
0h000C
DC link voltage
1
V
R
-
0h000D
Output power
0.1
kW
R
-
0h000E
Operation status
-
-
R
B15
0: HAND, 1: AUTO
B14
1: Frequency command
source by communication
(built-in, option)
B13
1: Operation command
source by communication
(built-in, option)
B12
Reverse operation
command
B11
Forward operation
